1. Product code: GBA534
2. Description：The only true one piece expansion anchor with the two sheared.
Specifications:
1. Features: For great tensile strength and hardness, it is given two heat treatments. With the two sheared and pre-expanded halves of the anchor, exerting a tremendous gripping force in wall of hole.
2. Type: Any head available as your
requirement.
3. Material: Carbon steel.
4. Coating: Yellow zinc plated or white blue zinc plated.
5. Size:
Size
Drill Dia(mm)
Min Drill Depth(mm)
Length(mm)
Quantity/box(pcs)
M5×25
5
20
25
100
M5×38
18
20
38
100
M5×50
30
20
50
100
M5×65
45
20
65
100
M6×38
10
28
38
100
M6×50
22
28
50
100
M6×65
37
28
65
100
M6×75
47
28
75
100
M6×88
60
28
85
100
M6×100
72
28
100
100
