1. Product code: GBA611
2. Description: Sleeve anchor with hex bolt cone-shaped nut.
Specifications:
1. Application: Suitable for cable, pipeline and other fields.
2. Features: Bigger washer enhances the fixation area. The plastic ring ensure moisture proof environment. Cone-shaped nut have lines in order to prevent from rotation.
3. Material: Carbon steel or stainless steel.
4. Finish: Yellow zinc plated or white blue zinc plated.
5. Size:
|
Bolt size |
Drill Dia |
Drill Depth |
Max thickness |
Shell Length |
|
M6×45 |
8 |
43 |
2 |
30 |
|
M6×60 |
9 |
43 |
15 |
45 |
|
M8×60 |
10 |
55 |
5 |
41 |
|
M8×80 |
11 |
55 |
15 |
62 |
|
M10×70 |
12 |
70 |
2 |
48 |
|
M10×100 |
14 |
70 |
25 |
75 |
|
M12×80 |
16 |
80 |
2 |
55 |
|
M12×110 |
16 |
80 |
25 |
87 |
|
M16×110 |
20 |
90 |
15 |
82 |
|
M20×130 |
25 |
105 |
25 |
100 |
